SZXYQ Has Launched Cat6 Network Cables: Featuring a Cross-Shaped Skeleton For Interference Resistance And Meeting Rohs Standards

Shenzhen Xinyaoqiang Technology Co., Ltd

2025,08,09

XZXYQ today officially launched the "Green Shield" series of Category 6 Network Cables. This product features an innovative cross-bone isolation structure and eco-friendly materials, achieving 10Gbps high-speed transmission while reducing carbon emissions by 35% compared to traditional network cables. It redefines the sustainable development standards for high-performance network cabling.

Ethernet Cables high-quality cables Cat6 Ethernet Cables

I. Core Technology Breakthroughs

1. Zero Interference Signal Architecture

PE cross-shaped skeleton physically isolates four pairs of twisted wires, reducing crosstalk (NEXT) by 60%.

Optional aluminum foil shielding layer (STP version), with shielding effectiveness reaching 65dB at 30MHz frequency.

2. Environmental Material Revolution

Sheath made of halogen-free flame-retardant PVC (passed IEC 60754-1 toxicity test).

Conductor contains 30% recycled copper, with DC resistance ≤ 7.5Ω/100m.

3. Extreme Environment Tolerance

Wide temperature range design (-20℃ to 80℃), passed 100,000 times bending test.

Anti-tensile nylon rope can withstand 15kg tensile force without breaking.

II. Technical Specifications

Parameter	Value
Standard	TIA/EIA-568-C.2, ISO/IEC 11801
Bandwidth	250MHz (10Gbps @ 55m)
Conductor	23AWG solid bare copper
Jacket	Flame-retardant PVC (UL VW-1)
Bending Radius	≥4× cable diameter

III. Target Applications

Smart Buildings: High-speed backbone wiring

Industry 4.0: PLC networks in factories

Home/Office: 4K video streaming and VoIP

Data Centers: ToR (Top of Rack) switching

IV. Sustainability Commitment

Manufacturing process reduces 35% carbon footprint vs. conventional cables.

Partners with Green Cable Initiative for end-of-life recycling.
