Type-C -Type-C
(Total 1 Products)-
Min. Order:1High - Performance Braided Cable: 80Gbps 240W with Thunderbolt 3/4 Compatibility Exceptional Data Transfer Speeds Our braided cable, as a top - tier USB-C Cable, is engineered to deliver lightning - fast data transfer rates of up to 80Gbps. As...
Type-C to Type-C (abbreviated as C2C) cables are increasingly important connection solutions in modern electronic devices. Its most prominent feature is that both ends adopt exactly the same USB-C interface that can be inserted in both directions, which greatly enhances the convenience of use. However, not all C2C cables are the same. They vary greatly in transmission speed, charging power and video transmission capacity depending on the functions and protocols they support.
Core Classifications:
-
By Function & Performance:
Charging-Only Cable (Basic):
-
Features: Typically does not support data transfer or only supports USB 2.0 speed (480Mbps). The primary function is charging devices.
-
Identification: May have no markings or only indicate charging power (e.g., 60W).
-
Use Case: Daily charging for phones, earphones, controllers, etc.
-
-
-
USB 2.0: Slow transfer speed (480Mbps), common in inexpensive or bundled cables.
-
USB 3.2 Gen 1 (USB 3.0/3.1 Gen 1): Transfer speeds up to 5Gbps, suitable for transferring large files or connecting external hard drives.
-
USB 3.2 Gen 2: Transfer speeds up to 10Gbps, the preferred choice for users with higher speed demands.
-
USB4 / Thunderbolt 3/4: Top-tier performance with speeds up to 40Gbps, supporting data, video, and power delivery simultaneously.
-
-
High-Speed Charging Cable (Power Delivery):
-
Features: Supports the USB Power Delivery (PD) Fast Charging protocol.
-
Power Ratings: Common ratings include 60W, 100W, and 240W (latest USB PD 3.1 EPR standard). Higher wattage enables faster charging for larger devices like laptops.
-
Identification: Often marked with the maximum power (e.g., 100W) on the cable.
-
-
Video Transmission Cable (Alt Mode):
-
Features: Supports DisplayPort or HDMI Alt Mode protocols, allowing video output to monitors, docks, or TVs.
-
Resolution: Supports video output from 1080p up to 8K or higher, depending on the cable's version and performance.
-
-
-
By Cable Specification:
-
Passive Cable: The most common type, with limited length (high-speed cables are usually shorter).
-
Active Cable: Contains internal chips to maintain high-speed signal integrity over longer distances, more expensive.
-
Function:
1.20W PD fast charging
It is equipped with an intelligent chip and is well compatible with Apple's PD fast charging protocol. When paired with a 20W PD charger, it can provide fast charging for the iPhone 12/13/14/15 series, significantly reducing the charging time. It only takes about 30 minutes to charge the battery to over 50%, effectively alleviating battery anxiety.
2. Stable data transmission
Supports USB 2.0 data transfer standard, with a maximum transfer rate of up to 480Mbps. It can be used to stably and efficiently synchronize photos, videos, files and perform device backups between iPhone and computer, meeting the daily data management needs.
It is equipped with an intelligent chip and is well compatible with Apple's PD fast charging protocol. When paired with a 20W PD charger, it can provide fast charging for the iPhone 12/13/14/15 series, significantly reducing the charging time. It only takes about 30 minutes to charge the battery to over 50%, effectively alleviating battery anxiety.
2. Stable data transmission
Supports USB 2.0 data transfer standard, with a maximum transfer rate of up to 480Mbps. It can be used to stably and efficiently synchronize photos, videos, files and perform device backups between iPhone and computer, meeting the daily data management needs.
Material
1. External Material
Outer Jacket material (Cable Jacket): PVC (polyvinyl chloride)
Feature: The product parameters clearly indicate that the material is PVC. This cable is made of specially treated flexible PVC material, which gives it a skin-friendly and delicate touch. This treatment makes it soft and smooth to the touch. Compared with ordinary PVC, it is more elastic, resistant to pulling and bending, and less likely to tangle.
2. Internal Structure
Internal Conductors: 4-Core Pure Copper Wire
Feature: It is composed of 4 thickened pure copper wires inside. The copper core is of high purity and good quality, with excellent electrical conductivity and low resistance. It can effectively support a large current of 6A passing through, ensuring high charging efficiency, low energy loss and good heat control. It is the basic guarantee for safe fast charging.
3. Connector Material
Lightning terminals and USB-A terminals (Connectors): Although not explicitly marked, according to industry standards, they are usually adopted
Plug Shell: ABS or PC plastic, ensuring the plug's sturdiness and durability.
Interface Pins: Tinned Copper or Gold-Plated treatment to enhance corrosion resistance and electrical conductivity, ensuring stable plugging and unplugging as well as good electrical connection.
Outer Jacket material (Cable Jacket): PVC (polyvinyl chloride)
Feature: The product parameters clearly indicate that the material is PVC. This cable is made of specially treated flexible PVC material, which gives it a skin-friendly and delicate touch. This treatment makes it soft and smooth to the touch. Compared with ordinary PVC, it is more elastic, resistant to pulling and bending, and less likely to tangle.
2. Internal Structure
Internal Conductors: 4-Core Pure Copper Wire
Feature: It is composed of 4 thickened pure copper wires inside. The copper core is of high purity and good quality, with excellent electrical conductivity and low resistance. It can effectively support a large current of 6A passing through, ensuring high charging efficiency, low energy loss and good heat control. It is the basic guarantee for safe fast charging.
3. Connector Material
Lightning terminals and USB-A terminals (Connectors): Although not explicitly marked, according to industry standards, they are usually adopted
Plug Shell: ABS or PC plastic, ensuring the plug's sturdiness and durability.
Interface Pins: Tinned Copper or Gold-Plated treatment to enhance corrosion resistance and electrical conductivity, ensuring stable plugging and unplugging as well as good electrical connection.
Standards
1. Electrical performance standards
Output capacity: The rated carrying current is 6A, ensuring stable fast charging at a power of 20W.
Protocol compatibility: The built-in chip accurately recognizes Apple's PD fast charging protocol and automatically matches the current required by the device, ensuring efficient and safe charging.
Data transmission: Complies with USB 2.0 standard, meeting the daily file synchronization and backup requirements.
2. Structure and Safety Standards:
Core structure: 4-strand oxygen-free pure copper core, with low resistance and high conductivity, effectively reducing energy loss and heat generation during the charging process.
Durability: The interface adopts injection molding reinforcement technology, effectively enhancing the bending resistance and extending the service life. The line body passed the regular swing test.
Material safety: The cables meet environmental protection standards (such as RoHS).
3. Appearance and Experience standards:
Interface design: 1:1 reproduction of the original Apple Lightning head design, ensuring smooth plugging and unplugging and excellent compatibility.
Warm reminder: To achieve the claimed 20W PD fast charging, your charger needs to support the 20W or higher PD protocol.
Output capacity: The rated carrying current is 6A, ensuring stable fast charging at a power of 20W.
Protocol compatibility: The built-in chip accurately recognizes Apple's PD fast charging protocol and automatically matches the current required by the device, ensuring efficient and safe charging.
Data transmission: Complies with USB 2.0 standard, meeting the daily file synchronization and backup requirements.
2. Structure and Safety Standards:
Core structure: 4-strand oxygen-free pure copper core, with low resistance and high conductivity, effectively reducing energy loss and heat generation during the charging process.
Durability: The interface adopts injection molding reinforcement technology, effectively enhancing the bending resistance and extending the service life. The line body passed the regular swing test.
Material safety: The cables meet environmental protection standards (such as RoHS).
3. Appearance and Experience standards:
Interface design: 1:1 reproduction of the original Apple Lightning head design, ensuring smooth plugging and unplugging and excellent compatibility.
Warm reminder: To achieve the claimed 20W PD fast charging, your charger needs to support the 20W or higher PD protocol.
Core Advantages
1. Fast as original: Supports Apple's 20W PD fast charging for rapid blood recovery.
2. Original experience: 1:1 interface design, smooth plugging and unplugging.
3. Skin-friendly touch: Flexible thread body, fine texture, not easy to tangle.
4. Safe and reliable: 4-core pure copper wire, 6A large current, durable and does not get hot.
5. Lightweight and portable: 1-meter golden length, suitable for multiple scenarios.
2. Original experience: 1:1 interface design, smooth plugging and unplugging.
3. Skin-friendly touch: Flexible thread body, fine texture, not easy to tangle.
4. Safe and reliable: 4-core pure copper wire, 6A large current, durable and does not get hot.
5. Lightweight and portable: 1-meter golden length, suitable for multiple scenarios.
FAQ
Q1: Can this data cable really support 20W fast charging? How about the speed?
A: Yes, I fully support it. This product is equipped with an intelligent chip and is well compatible with Apple's 20W PD fast charging protocol. When used with a 20W PD charger, it can charge your iPhone 12/13/14/15 series devices to over 50% in about 30 minutes, significantly enhancing charging efficiency and saying goodbye to battery anxiety.
Q2: Does it support data transmission? How about the speed?
A: Supported. This product supports the USB 2.0 data transfer standard, with a maximum transfer rate of 480Mbps (approximately 60MB/s), which is sufficient to meet the daily needs of synchronizing photos, videos, files and device backups, and is stable and efficient.
Q3: What is "skin-friendly feel"? What's the difference from an ordinary data cable?
A: "Skin-friendly feel" refers to the fact that the outer layer of our cables is made of specially formulated flexible PVC material, which has a fine, soft and smooth touch, similar to the texture of the skin. Compared with the stiff plastic feel of ordinary data cables, it feels more comfortable and is less prone to tangling and knotting, providing an upgraded experience.
Q4: Is the wire durable? Is the interface prone to damage?
A: We attach great importance to durability. The interior adopts 4 thickened pure copper wire cores, which have good electrical conductivity and low heat generation. In addition, the connection between the cable and the connector has been reinforced, effectively enhancing the bending resistance. It is more durable and has a longer service life than ordinary wires.
