UL-1015 High-Temperature Hook-Up Wire
UL-1015 High-Temperature Hook-Up Wire

UL-1015 High-Temperature Hook-Up Wire

  • Payment Type: L/C,T/T,D/P,Paypal
  • Incoterm: FOB
  • Min. Order: 1
  • Transportation: Ocean,Land,Air,Express
Contact Us
Get Latest Price
    PRODUCT ATTRIBUTES
    Overview
    Product Attributes

    Model No.: 002138

    Place Of Origin: China

    Insulation Material: Pvc

    Cable Height: Customizable height of the cable as per design

    Cable Length: Length of the cable, customizable per order

    Certification: ROHS 2.0 & Reach

    Overview
    Supply Ability & Additional Information

    Transportation: Ocean,Land,Air,Express

    Payment Type: L/C,T/T,D/P,Paypal

    Incoterm: FOB

    Packaging & Delivery
    Product Description
    Parameter Detail Parameter Detail
    Temperature Rating 105℃ Standards UL 758, UL 1581, CSA C22.2 No.210.2
    Voltage Rating 600V AC Environmental RoHS 2.0, REACH Compliant
    Conductor Solid/Stranded Tinned/Bare Copper (30-10AWG) Processing Uniform thickness, easy stripping/cutting
    Insulation PVC Applications Appliances,Industrial Controls,Power Supplies,Electrical Equipment
    Flame Ratings UL VW-1, CSA FT1, JQA F-Mark
    Product Details
    1. Overview
    The UL-1015 is a general-purpose hook-up wire designed for high-temperature electrical applications. Its robust construction meets stringent North American (UL/CSA) and international (JQA) safety standards, ensuring reliable performance in demanding environments.
    2. Key Features
    Heat Resistance: Stable performance at 105℃, ideal for enclosed spaces.
    Safety Certified: Triple flame ratings (VW-1/FT1/F-Mark) for reduced fire risk.
    Easy Installation: Precision insulation thickness for effortless stripping and termination.
    Versatile Conductors: 30-10AWG options for flexible current loads (3A~30A).
    3. Typical Applications
    Internal wiring for ovens, transformers, and power tools.
    Control cabinets and industrial machinery connections.
    HVAC systems and lighting equipment.
    4. Quality Assurance
    100% continuity and hi-pot testing.
    Third-party certifications available (UL/CSA files).
    5. Customization
    Available in custom lengths/spool sizes.
    Color-coding options (up to 10 standard colors).
    Marketing Suggestions
    Title for E-commerce:
    [UL Listed] UL-1015 600V Wire | 105℃ Rated | VW-1/FT1 Certified | 30-10AWG
    Images to Highlight:
    Cross-section showing conductor/insulation.
    Flame test comparison with non-rated wires.
    Industrial control panel installation example.

    Our UL-1015 Cable stands as a benchmark among high-quality cables, designed to deliver exceptional performance in diverse electronic and electrical setups. As a core part of our reliable wiring solutions, it meets stringent industry standards to ensure safety and durability.

    Crafted for versatility, this cable operates at a rated temperature of 105℃ and a rated voltage of 600V AC, with conductors available in single or stranded 30~10AWG tinned or bare copper. Its PVC insulation is engineered for uniformity, making it easy to handle during installation. Adhering to UL758, UL1581, and CSA C22.2 No.210.2 standards, it aligns with the rigor expected of UL Cables, ensuring compliance with global safety norms.

    Environmental responsibility is a key focus: the cable meets ROHS 2.0 and Reach standards, while passing UL VW-1, CSA FT1, and JQA F-Mark flame retardant tests for enhanced safety. Beyond its technical strengths, it integrates seamlessly with various setups, complementing other wiring components like Ethernet Cables and USB-C Connectors in complex electronic systems.

    Whether used in general electronic devices or precision equipment, this cable’s consistent insulation thickness, easy cutting, and easy stripping make it a practical choice. Trust our UL-1015 Cable to deliver stable performance as a critical internal connecting wire, backed by the quality that defines our range of UL Cables and wiring solutions.
    FAQ:
    Q: Suitable for outdoor use?
    A: For indoor/covered environments only (not UV-resistant).
    Q: MOQ?
    A: Standard 500ft spools; custom cuts available.
    (Note: Include testing reports and compliance certificates for B2B buyers.)
